IHG140
IZMAC Hydraulic Gas & Oil type Buffer
IHG140
Hydraulic Gas & Oil type Buffer
Body Thread Size : 140
Stroke : 100, 200, 300, 400, 500, 600, 800, 1000
Body Thread Size : 140
Stroke : 100, 200, 300, 400, 500, 600, 800, 1000
Installation Size
| Image | Model | Stroke (mm) |
Max.Energy/ Cycle(KJ)ET |
Max.Buffer Force(kN)Fs |
|---|---|---|---|---|
 |
IHG140-100 | 100 | 55 | 688 |
 |
IHG140-200 | 200 | 110 | 688 |
 |
IHG140-300 | 300 | 165 | 688 |
 |
IHG140-400 | 400 | 220 | 688 |
 |
IHG140-500 | 500 | 270 | 688 |
 |
IHG140-600 | 600 | 300 | 630 |
 |
IHG140-800 | 800 | 325 | 510 |
 |
IHG140-1000 | 1,000 | 360 | 450 |
